Is possible to open AR Capture on Portraite Mode on Android?

Mike · 16-May-2016 16:33:31

How to export to Android, forcing the camera to capture image on vertical or Portraite mode...

arkeon · 16-May-2016 16:37:50

no there is not actually.
but I don't understand the difference for video output. since the camera orientation do not matter for the input/output picture ?!

Mike · 16-May-2016 17:53:29

The Apk is for Android Mobile Phone, where the marker image height is long and the widht is short, the video overlay is a animation of the marker image.

The tranparent video effect, shows the marker geting alive, so the orientation of the camera must be equal to the sreen display.

Any idea.. ? Thanks

arkeon · 16-May-2016 18:04:44

I don't understand the issue.
you can just rotate the marker picture or the 3D model.

el_motoblock · 16-May-2016 19:14:00

Mike, visual draw on the picture to make it clear

Last edited by el_motoblock (16-May-2016 19:14:30)

Mike · 16-May-2016 20:08:34

Im looking for a solution similar to these FluxBB bbcode test , that´s why the importance for the alignement with the camera view!

arkeon · 17-May-2016 00:06:05

ok so just add your object on a dummy and adjust the rotation like you can see on video tutorials.
the camera orientation is not involved in this. what is the result on your app ?

arkeon · 17-May-2016 10:02:46

If I understand correctly what you want is to do an app in portrait mode.
I think you can do it simply by creating a rotated HUD.
I mean without changing anything in the android manifest. just create your hud already rotated. make your buttons bitmaps rotated by 90° and align on the right, so it will appear on bottom on the phone.

Mike · 17-May-2016 13:12:31

Yes i just pretend an app in portrait mode, aligning the view of the real world from camera, with the overlay image/video/3D, a augmented reality like this example:
FluxBB bbcode test

How to create a rotated HUD, is that a PlugIT?

Last edited by Mike (17-May-2016 13:13:55)

arkeon · 17-May-2016 13:42:36

for the buttons you want on the screen bottom, just rotate the button image in your image editor and align it to the right / center of the screen. so it will appear on the bottom on your phone.

afrina · 28-Jun-2016 04:04:28

Can we rotate the video and the camera as well?

arkeon · 28-Jun-2016 17:00:44

hmm no you can't ^^

for the video you can use a 3D plan with the video on it and position the 3D the way you want

arkeon · 4-Oct-2016 14:16:18

In next release the orientation mode is available and the camera is managed for portrait mode.

arkeon · 5-Oct-2016 09:51:39

you can download https://svn.scolring.org/trunk/setups/a … ndroid.exe
and change the manifest manually to portrait mode to test it
for front camera (index 1) enable mirror on ArCapture plugIT

shahbiz8 · 3-Jul-2017 14:48:31

Hi..just asking if in a same app (export in portait mode), I want AR capture image 1 in landscape view then AR capture image 2 in portrait view, how to do like this example? just rotate the button for landscape view?

arkeon · 3-Jul-2017 14:53:25

Hello,
I'm not sure to understand your question correctly.

In portrait mode you can only get a screen shot in portait.

shahbiz8 · 3-Jul-2017 14:58:04

I think i understand now, rotate 3d object & button

Last edited by shahbiz8 (3-Jul-2017 15:02:54)

arkeon · 3-Jul-2017 16:41:21

This post was before the support of portrait mode on export.
You should just use the desired mode in export options
